114
-
Control box
Solenoid valve
Lower pressure sensor
(LPT)
Service valve
Service valve
(Liquid side)
(Gas side)
Compressor
High pressure switch
(63H1)
Electronic expansion
valve (heating)
(SM2)
Electronic expansion
valve (cooling)
(SM1)
(SV2)
Models FDCVA402HENAR, 502HENAR, 602HENAR
402HESAR, 502HESAR, 602HESAR
Model FDCVA802HESAR
Control box
High pressure switch
Electronic expansion valve
(cooling)
Electronic expansion valve
(heating)
Service valve
Service valve
(Liquid side)
Lower pressure sensor
(LPT)
(Gas side)
Compressor
(63H1)
(SM1)
(SM2)
