Typical Power Consumption
(without Special Connection
Modules)
AL-6MR-A, 240V AC~ I/O all On - 2.5 W, I/O all Off - 1.5 W
AL-6MR-A, 120V AC~ I/O all On - 2.0 W, I/O all Off - 1.2 W
AL-10MR-A, 240V AC~ I/O all On - 3.0 W, I/O all Off - 1.5 W
AL-10MR-A, 120V AC~ I/O all On - 2.5 W, I/O all Off - 1.2 W
AL-10MR-D, 24V DC I/O all On - 2.0 W, I/O all Off - 0.3 W
AL-10MT-D, 24V DC I/O all On - 2.0 W, I/O all Off - 0.3 W
AL-20MR-A, 240V AC~ I/O all On - 5.0 W, I/O all Off - 1.5 W
AL-20MR-A, 120V AC~ I/O all On - 4.0 W, I/O all Off - 1.2 W
AL-20MR-D, 24V DC I/O all On - 5.0 W, I/O all Off - 0.3 W
AL-20MT-D, 24V DC I/O all On - 5.0 W, I/O all Off - 0.3 W
Table 2.2: Power Supply Specifications
Description Code Specification
