α
Simple Application Controller
Hardware Specification 2
3
ENG
2.
Hardware
Specification
2.1 Available Models
* Without Special Connection Modules.
Table 2.1:Model Table
Model Power Supply
Input Output Dimensions Weight
Typ e Number Ty p e Number mm (inches) kg (lbs)
AL-6MR-A
100 - 240V
AC~
100 - 240V
AC~
4RELAY 2
71.2 x 90 x 55
(2.80 x 3.54 x
2.17)
0.20
(0.44)
AL-10MR-A 6 RELAY 4
AL-10MR-D
24V DC
24V DC
Sink/Source
6RELAY 4
AL-10MT-D 6 TRANSISTOR 4
AL-20MR-A
100 - 240V
AC~
100 - 240V
AC~
12 RELAY 8
124.6 x 90 x 55
(4.91 x 3.54 x
2.17)
0.32
(0.70)*
AL-20MR-D
24V DC
24V DC
Sink/Source
12 RELAY 8
AL-20MT-D 12 TRANSISTOR 8
