Ocupaciones de bornas 5
22
ESP
AL-20MR-A, Entrada CA, salida del relé
AL-20MR-D, Entrada CC, salida del relé
AL-20MT-D, Entrada CC, salida del transistor
LN
IN
121112345678910
OUT1
OUT2 OUT3 OUT5 OUT7OUT4 OUT6 OUT8
AL-20MR-A
+
-
IN
121112345678910
OUT1
OUT2 OUT3 OUT5 OUT7OUT4 OUT6 OUT8
AL-20MR-D
(A) (B)
+
-
IN
121112345678910
OUT1 OUT2
OUT3 OUT5 OUT7OUT4 OUT6 OUT8
AL-20MT-D
(A) (B)
