Mitsubishi AL2-14MR-D

35
Now you are ready to set the blocks parameters.
The Day lighting operates each and every weekday. It will turn on at 8:00am then turn off at
16:30.
Double click the Time Switch Block. This dialog box will appear:
Click this button to create a new
time
1. Switch ON
2. Every week
3. Every weekday
4. At 8:00am
5. OK
Q u i c k S t a r t G u i d e
Mitsubishi Alpha / Alpha2
Programmable Controller
