Mitsubishi DY-1MU3R45-T User Manual

Ref. No. Parts No. Parts Name Note Spec.
Base Parts No.
Ref. No. Parts No. Parts Name Note Spec.
Base Parts No.
R883 103L240O6 R-CHIP RMC1/8270JATP 1/4W 270J 3216 N931L86312 R996 103P124O6 R-CHIP HPC03CT623D 1/16W 623D 1005 N931L86312
R884 103L240O6 R-CHIP RMC1/8270JATP 1/4W 270J 3216 N931L86312 R998 103P124O7 R-CHIP HPC03CT753D 1/16W 753D 1005 N931L86312
R885 103L241O7 R-CHIP RMC1/8221JATP 1/4W 221J 3216 N931L86312 R9A1 103L242O5 R-CHIP RMC1/8102JATP 1/4W 102J 3216 N931L86312
R886 103P154O5 R-CHIP RMC1/16S473JTH 1/16W 473J 1005 N931L86312 R9A2 103L293O9 R-CHIP RMC1/16153JTP 1/10W 153J 1608 N931L86312
R890 103P154O5 R-CHIP RMC1/16S473JTH 1/16W 473J 1005 N931L86312 R9A3 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312
R891 103L193O7 R-CHIP RMC1/10103JATP 1/8W 103J 2125 N931L86312 R9A4 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R892 103L193O7 R-CHIP RMC1/10103JATP 1/8W 103J 2125 N931L86312 R9A5 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R899 103P152O7 R-CHIP RMC1/16S152JTH 1/16W 152J 1005 N931L86312 R9B1 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312
R8E1 103L241O4 R-CHIP RMC1/8121JATP 1/4W 121J 3216 N931L86312 R9B3 103L242O9 R-CHIP RMC1/8222JATP 1/4W 222J 3216 N931L86312
R8E4 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312 R9B4 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R8E5 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312 R9B5 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R8K1 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312 R9C1 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312
R8K5 103P154O5 R-CHIP RMC1/16S473JTH 1/16W 473J 1005 N931L86312 R9C2 103L242O2 R-CHIP RMC1/8561JATP 1/4W 561J 3216 N931L86312
R8K6 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312 R9C3 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N931L86312
R8K7 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312 R9C4 103L291O9 R-CHIP RMC1/16331JTP 1/10W 331J 1608 N931L86312
R8W1 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N931L86312 R9C5 103P172O6 R-CHIP RPC03T132F 1/16W 132F 1005 N931L86312
R8W2 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N931L86312 R9C6 103P163O4 R-CHIP RMC1/16S562FTH 1/16W 562F 1005 N931L86312
R8W3 103P159O9 R-CHIP RMC1/16SJPTH 1/16W 0 1005 N931L86312 R9C7 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R8W5 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312 R9C8 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R8W6 103L309O9 R-CHIP RPC50T0R0 1/2W 0 5025 N931L86312 R9F1 103P159O9 R-CHIP RMC1/16SJPTH 1/16W 0 1005 N931L86312
R8W7 103L309O9 R-CHIP RPC50T0R0 1/2W 0 5025 N931L86312 R9F3 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R917 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N931L86312 R9F4 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R918 103L244O9 R-CHIP RMC1/8104JATP 1/4W 104J 3216 N931L86312 R9F5 103P503O0 R-CHIP RMC1/16272FTP 1/10W 272F 1608 N931L86312
R921 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312 R9F6 103P503O4 R-CHIP RMC1/16562FTP 1/10W 562F 1608 N931L86312
R922 103P53530 R-CHIP RPZ10T272F 1/4W 272F 2125 N931L86312 R9F7 103P503O6 R-CHIP RMC1/16822FTP 1/10W 822F 1608 N931L86312
R923 103P53530 R-CHIP RPZ10T272F 1/4W 272F 2125 N931L86312 R9F8 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312
R924 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312 R9F9 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312
R931 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312 R9F
A
103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N931L86312
R932 103L242O5 R-CHIP RMC1/8102JATP 1/4W 102J 3216 N931L86312 R9FB 103P158O0 R-CHIP RPC03T1R0J 1/16W 1R0J 1005 N931L86312
R933 103L192O5 R-CHIP RMC1/10102JATP 1/8W 102J 2125 N931L86312 R9FC 103L291O2 R-CHIP RMC1/16820JTP 1/10W 820J 1608 N931L86312
R934 103L193O4 R-CHIP RMC1/10562JATP 1/8W 562J 2125 N931L86312 R9FD 103L294O5 R-CHIP RMC1/16473JTP 1/10W 473J 1608 N931L86312
R935 103L413O3 R-CHIP RGC1/10C472DTP 1/10W 472D 2125 N931L86312 R9G1 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N931L86312
R936 103L413O9 R-CHIP RGC1/10C153DTP 1/10W 153D 2125 N931L86312 R9G5 103L299O9 R-CHIP RMC1/16JTP 1/10W 0 1608 N931L86312
R937 103L191O3 R-CHIP RMC1/10101JATP 1/8W 101J 2125 N931L86312 R9G6 103L294O3 R-CHIP RMC1/16333JTP 1/10W 333J 1608 N931L86312
R941 103L253O3 R-CHIP RMC1/10472FATP 1/8W 472F 2125 N931L86312 R9J1 103P152O9 R-CHIP RMC1/16S222JTH 1/16W 222J 1005 N931L86312
R942 103L253O0 R-CHIP RMC1/10272FATP 1/8W 272F 2125 N931L86312 R9J2 103P152O9 R-CHIP RMC1/16S222JTH 1/16W 222J 1005 N931L86312
R943 103L194O9 R-CHIP RMC1/10104JATP 1/8W 104J 2125 N931L86312 R9K1 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312
R944 103L254O5 R-CHIP RMC1/10473FATP 1/8W 473F 2125 N931L86312 R9K2 103L242O5 R-CHIP RMC1/8102JATP 1/4W 102J 3216 N931L86312
R951 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N931L86312 R9W1 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R952 103L294O9 R-CHIP RMC1/16104JTP 1/10W 104J 1608 N931L86312 R9W2 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R953 103L244O7 R-CHIP RMC1/8683JATP 1/4W 683J 3216 N931L86312 R9W4 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R954 103L294O1 R-CHIP RMC1/16223JTP 1/10W 223J 1608 N931L86312 R9W5 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R961 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312 R9W6 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R962 103L292O5 R-CHIP RMC1/16102JTP 1/10W 102J 1608 N931L86312 R9W7 351P12263 COIL-CHIP BK2125LM252-T LM252 2125 N931L86312
R963 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312 R9W8 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312
R964 103L293O3 R-CHIP RMC1/16472JTP 1/10W 472J 1608 N931L86312 RG1 443P01012 TERMINAL SD01123-21 N931L86312
R971 103L199O9 R-CHIP RMC1/10JPATP 1/8W 0 2125 N931L86312 RG2 443P01012 TERMINAL SD01123-21 N931L86312
R972 103L294O0 R-CHIP RMC1/16183JTP 1/10W 183J 1608 N931L86312 RG3 443P01012 TERMINAL SD01123-21 N931L86312
R973 103L242O2 R-CHIP RMC1/8561JATP 1/4W 561J 3216 N931L86312 RG4 443P01012 TERMINAL SD01123-21 N931L86312
R974 103L294O0 R-CHIP RMC1/16183JTP 1/10W 183J 1608 N931L86312 X171 285P101O7 CRYSTAL-TAPE SMD-49 PB-FREE 4.332MHZ N931L86312
R975 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312 X301 285P13915 CRYSTAL-CHIP DSX321G 22.5792MHZ 22.5792MHZ N931L86312
R976 103P153O2 R-CHIP RMC1/16S392JTH 1/16W 392J 1005 N931L86312 X801 285P098O3 CRYSTAL-TAPE DMX-26 SN PB-FREE 32.768KHZ,6PF N931L86312
R978 103L293O2 R-CHIP RMC1/16392JTP 1/10W 392J 1608 N931L86312 X802 285P13914 CRYSTAL-CHIP DSX321G 20.000MHZ 20.000MHZ N931L86312
R980 103P153O1 R-CHIP RMC1/16S332JTH 1/16W 332J 1005 N931L86312 X850 285P13610 CRYSTAL-CHIP CX3225SB48000C0GPQZZ 48MHZ N931L86312
R981 103P504O4 R-CHIP RMC1/16393FTP 1/10W 393F 1608 N931L86312 X870 285P12712 CRYSTAL-CHIP DSX530GA-16.9344MHZ 16.9344MHZ N931L86312
R982 103P502O5 R-CHIP RMC1/16102FTP 1/10W 102F 1608 N931L86312 Z101 299P135O3 PROTECTOR-CHIP 6801-01Y903 N931L86312
R984 103L292O1 R-CHIP RMC1/16471JTP 1/10W 471J 1608 N931L86312
R985 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312
R986 103L293O7 R-CHIP RMC1/16103JTP 1/10W 103J 1608 N931L86312
R987 103P503O7 R-CHIP RMC1/16103FTP 1/10W 103F 1608 N931L86312
R988 103P151O3 R-CHIP RMC1/16S101JTH 1/16W 101J 1005 N931L86312
R990 103P514O1 R-CHIP RMC1/16243FTP 1/10W 243F 1608 N931L86312
R992 103P503O6 R-CHIP RMC1/16822FTP 1/10W 822F 1608 N931L86312
R993 103P153O7 R-CHIP RMC1/16S103JTH 1/16W 103J 1005 N931L86312
