Mitsubishi ECLIPSE 2011 - Page 139

3-44
Features and controls
3
4. Slide the slide (C) toward the middle to unlock the bottom
frame (A) and the top frame (B).
5. Move the locking pin (D) to the position (1).
C
1- Stowed position
2- Installation position
3- Locked position
D321
