EXHAUST MANIFOLD AND TURBOCHARGER
TSB Revision
INTAKE AND EXHAUST
15-18
5. Turbocharger air outlet fitting
gasket
<<A>> >> F <<
6. Turbocharger compressor
bracket
7. Turbocharger air inlet fitting
8. Turbocharger air inlet fitting
gasket
9. Turbocharger water feed hose
10. Turbocharger water feed pipe
11. Gasket
12. Turbocharger water return hose
>> E <<
13. Turbocharger exhaust outlet
fitting bracket
14. Transfer heat protector
15. Drive shaft heat protector
16. Steering gear and linkage heat
protector
17. Turbocharger protector A
18. Turbocharger protector B
19. Emission vacuum control hose
connection
20. Turbocharger pin
<< B >>
21. Waste gate actuator
22. Turbocharger exhaust outlet
fitting
23. Turbocharger exhaust outlet
fitting gasket
>> C <<
24. Turbocharger bracket and
turbocharger assembly coupling
bolt
25. Turbocharger oil feed tube
connection
26. Gasket
27. Turbocharger oil return tube
connection
28. O-ring
>> D <<
29. Exhaust manifold and
turbocharger assembly coupling
bolt and nut
30. Exhaust manifold
31. Exhaust manifold gasket
32. Turbocharger gasket
33. Turbocharger assembly
•
Transfer assembly (Refer to
GROUP 22A, Transfer Assembly
P.22A-125 <M/T>), (Refer to
GROUP 22C, Transfer Assembly
P.22C-339 <TC-SST>)
>> C <<
34. Turbocharger bracket
Removal steps (Continued)
