VEHICLE ELECTRICAL COMPONENTS
No. Monitor name When OFF When ON or flashing Remarks
Controller/motor Controller, drive motors and Overheating Overheating causes a
overheat indicator
pump motor in normal
significant output loss. When
3
temperature
component temperature
returns
to normal l
evels, output power
returns.
Remaining Normal battery condition Flashing indicates
battery charge battery needs to be
warning light recharged soon.
4 ON indicates battery
needs to be recharged
and lifting function
inoperable.
5
Brake fluid level indicator
Normal fluid level Low fluid level
6 Parking brake warning Parking brake disengaged Parking brake
light disengaged
7 Malfunction lamp Normal Vehicle malfunction
8
Speedometer
KPH, MPH
Error indicator
9
Battery discharge When no bars show, vehicle is drivable but lifting Indicates remaining battery
indicator function is inoperable. power.
Hour meter
10
12345
Advances every 0.1 hour
(Number advances every 6 minutes.)
