Mitsubishi FB16NT User Manual

HOW TO READ THIS MANUAL
Disassembly diagram (example)
Sequence
1. Cover, Bolt, Washer (part name)
2. Output shaft (part name)
Suggestion for disassembly
(1) Output shaft removal
Unit: mm (in.)
A
0.020 to 0.105
Clearance between
(0.00079 to 0.00413)
cylinder and piston
0.15
B
(0.0059)
A: Standard value B: Repair or service limit
Disassembly sequence
Each disassembly diagram is followed
by Disassembly sequence and
Suggestions for disassembly.

Mitsubishi FB16NT Specifications

General

Brand	Mitsubishi
Model	FB16NT
Category	Boom Lifts
Language	English
