GENERAL INFORMATION
Technical Data
Truck Models FB16NT FB18NT FB20NT
Class 1.6 ton 1.8 ton 2.0 ton
Load Capacity/Load Center N (kgf)/mm 15690 (1600)/500 17650 (1800)/500 19610 (2000)/500
[lbf/in.] [3500/20] [4000/20] [4400/20]
Truck size Length to Fork Face A mm (in.) 1893 (74.5) 1996 (78.6) 2032 (80.0)
W idth B mm (in.) 1070 (42.1) 1070 (42.1) 1130 (44.5)
Height of Overhead
C 2048 (80.6) 2048 (80.6) 2048 (80.6)
Guard mm (in.)
Wheelbase D mm (in.) 1307 (51.5) 1410 (55.5) 1410 (55.5)
Service Weight (including battery) kg (lb) 3090 (6812) 3290 (7253) 3520 (7760)
Tread Front/Rear E/F
mm 913/170 913/170 935/170
(in.) (35.9/6.7) (35.9/6.7) (36.8/6.7)
Tires Number Front/Rear 2/2 2/2 2/2
Tires Size Front 18 × 7-8 18 × 7-8 200/50-10
Rear 15 × 4.5-8 15 × 4.5-8 140/55-9
Turning Radius mm (in.) 1517 (59.7) 1620 (63.8) 1645 (64.8)
Travel Speeds Unloaded/Loaded km/h (mph) 17/17 (10.6/10.6) 17/17 (10.6/10.6) 17/17 (10.6/10.6)
Gradeability Loaded
27 25 23
[5 min., at 1.6 km/h (1.0 mph)] %
Lift Speeds Unloaded/Loaded m (in.)/sec 0.60/0.50 (23.6/19.7) 0.60/0.44 (23.6/17.3) 0.60/0.40 (23.6/15.7)
Lowering Speed Unloaded/Loaded m (in.)/sec 0.50/0.52 (19.7/20.5) 0.50/0.52 (19.7/20.5) 0.50/0.52 (19.7/20.5)
Battery Voltage V 48 48 48
Battery Rated Capacity (5 hrs.) MAX Ah 600 720 720
Battery Compartment mm 521 × 1006 × 650 624 × 1006 × 650 624 × 1006 × 650
Length × Width × Height (in.) (20.5 × 39.6 × 25.6) (24.6 × 39.6 × 25.6) (24.6 × 39.6 × 25.6)
Tilt Angle (forwards-backwards) 6°-7° 6°-7° 6°-7°
Traction Motor, 60 min short duty kW 2 × 6.3 2 × 6.3 2 × 6.3
Hydraulic Motor kW 14 14 14
Traction Motor Control Method MOSFET MOSFET MOSFET
Hydraulic Motor Control Method MOSFET MOSFET MOSFET
