FX2N-5A Special function block Specifications 6
6-2
Table 6.2: Power supply specifications
Item Specifications
Interface driving
power supply
24 V DC±10%, 90 mA (maximum), externally supplied
CPU driving power
supply
5 V DC, 70 mA, supplied via extension cable from PLC main unit
Table 6.3: Performance specifications
Item Specifications
Conversion speed
Channel for voltage/current input: 1 ms x Number of used channels
Channel for voltage/current output: 2 ms
(See BFM 25)
Insulation method
Photocoupler insulates the analog input/output area from PLC.
DC/DC converter insulates the power supply from analog I/O.
Channels are not insulated against each other.
Number of occupied
I/O points
8 points (including input and output points)
Applicable PLC
FX
0N
, FX
1N
, FX
2N
, FX
2NC
Series PLC
(For connection to FX
2NC
Series PLC, FX
2NC
-CNV-IF is required.)
Built-in memory EEPROM
