FX2N-5A Special function block Buffer Memory (BFM) 7
7-2
7.1 Buffer Memories (BFM) lists
Table 7.1: BFM Lists
BFM
No.
Description
Hold against
power failure
Initial value
#0 Specifies input mode of CH1 to CH4.
"
H0000 at shipment
#1 Specifies output mode of CH1.
"
H0000 at shipment
#2 Number of averaging times for CH1 Setting range: 1 to 256 times
8
#3 Number of averaging times for CH2 Setting range: 1 to 256 times
8
#4 Number of averaging times for CH3 Setting range: 1 to 256 times
8
#5 Number of averaging times for CH4 Setting range: 1 to 256 times
8
#6 CH1 Data (average data)
―
#7 CH2 Data (average data)
―
#8 CH3 Data (average data)
―
#9 CH4 Data (average data)
―
#10 CH1 data (immediate data)
#11 CH2 data (immediate data)
#12 CH3 data (immediate data)
#13 CH4 data (immediate data)
#14 CH1 output data
K0
#15
Calculated Analog output data if direct output control function is
active (= BFM 14 + effective direct output value)
K0
#16 Reserved
#17 Reserved
