Mitsubishi FX2N-5A User Manual

FX2N-5A Special function block Specifications 6
6-5
Table 6.5: Voltage/current output specifications
Item Voltage output Current output
Analog output range
-10 to +10 V DC
(External load resistance:2 k
Ω
to 1M
Ω
)
Adjustment is enabled with the
following conditions:
Offset value: -32000 to +5000 mV
Gain value: -5000 to +32000 mV
"Gain - Offset":
>
1000 mV
(Resolution is constant.)
Change is disabled while absolute
voltage output mode is used.
0 to 20 mA DC, 4 to 20 mA DC
(External load resistance:500
Ω
or less)
Adjustment is enabled with the
following conditions:
Offset value: -32000 to +10000
µ
A
Gain value: -10000 to +32000
µ
A
"Gain - Offset":
>
1000
µ
A
(Resolution is constant.)
Change is disabled while absolute
current output mode is used.
Digital output Signed 12-bit binary 10-bit binary
Resolution
5mV (20 V
×
1/4000)
-10 to +10V at output
10
µ
A (40 mA
×
1/4000)
0 to 20 mA at output
4 to 20mA at output
Total accuracy
Ambient temperature: 25
°
C ± 5
°
C
±0.5%(±100mV) against full scale 20V
Ambient temperature: 0 to +55
°
C
±1.0%(±200mV) against full scale 20V
Ambient temperature: 25
°
C ± 5
°
C
±0.5% (0 to 20mA at output ±200
µ
A)
against full scale 40 mA
4 to 20mA output is same (±200
µ
A)
Ambient temperature: 0 to +55
°
C
±1.0% (0 to 20mA at output ±200
µ
A)
against full scale 40 mA
4 to 20mA output is same (±400
µ
A)
