FX2N-5A Special function block Buffer Memory (BFM) 7
7-29
Table 7.4: Bit assignment in BFM 26
Bit No. Channel No. Description
b0 CH1 average data lower limit value alarm
b1 average data upper limit value alarm
b2 CH2 average data lower limit value alarm
b3 average data upper limit value alarm
b4 CH3 average data lower limit value alarm
b5 average data upper limit value alarm
b6 CH4 average data lower limit value alarm
b7 average data upper limit value alarm
b8 CH1 immediate data lower limit value alarm
b9 immediate data upper limit value alarm
b10 CH2 immediate data lower limit value alarm
b11 immediate data upper limit value alarm
b12 CH3 immediate data lower limit value alarm
b13 immediate data upper limit value alarm
b14 CH4 immediate data lower limit value alarm
b15 immediate data upper limit value alarm
