Mitsubishi FX2N-5A User Manual

FX2N-5A Special function block Adjustment of I/O Characteristics 8
8-3
2.Current input, -20 to 20mA
→
-32000 to +32000 3.Voltage input, -100 to 100mA
→
32000 to +32000
4.Voltage input, -100 to 100mA
→
-2000 to +2000 5.Voltmeter mode, direct display, -10 to 10V
Digital value
-20
20
32000
Approx.32767
Approx.
20.480mA
Approx.
-20.480mA
-32000
Approx.-32768
Input
current
(mA)
0
Digital value
-100
100
32000
Approx.32767
Approx.
102.397mV
Approx.
-102.400mV
-32000
Approx.-32768
Input
voltage
(mV)
Digital value
-100
100
2000
Approx.2047
Approx.
102.397mV
Approx.
-102.400mV
-2000
Approx.-2048
Input
voltage
(mV)
Digital value
-10
10
10000
Approx.10239
Approx.
10.240V
Approx.
-10.240V
-10000
Approx.-10240
Input
voltage
(V)
