Wheel Speed Sensor
35B-33
WHEEL SPEED SENSOR
REMOVAL AND INSTALLATION
Post-installation Operations
Wheel speed sensor output voltage measurement
(Refer to P.35B-27.)
Front
Rear
1
2
3
4
5
6
Front wheel speed sensor removal
steps
A
A
"
1. Front wheel speed sensors
2. Front ABS rotor protector
3. Front ABS rotor
(Refer to GROUP 26 - Drive Shaft.)
Rear wheel speed sensor removal
steps
A
B
"
4. Rear wheel speed sensor
5. Rear ABS rotor protector
6. Rear ABS rotor
(Refer to GROUP 27 - Drive Shaft.)
NOTE
The front and rear ABS rotors are integrated with
the drive shaft and cannot be disassembled.
