Mitsubishi Outlander PHEV 2019

44
10) Raise the vehicle and then use a 12mm wrench to remove the battery protector.
<For 3 bolts type>
<For 4 bolts type>
11) Place the drain plug gasket (MB992947) and the drain plug cover (MB992946) in that order on the
bottom of the drain plug. Then hold them against the bottom of the battery using a jack
Reference) ・ MB992947:Drain plug gasket
(Silicone rubber sheet: approx. 70 x 70 x 3 mm) (2.75" x 2.75" x 1.25").
MB992946
Drain plug cover
MB992947
Drain plug gasket
Drain plug
MB992947
Drain plug
gasket
Jack
MB992946
Drain plug
cover
Front of vehicle
Battery protector
Front side
Bottom view
Bottom view
Battery protector
Front side
