10
4. Inside tailgate release
The inside tailgate release is designed to provide a way to open the tailgate in the case of a discharged auxiliary battery.
1) Open the lid (A) inside of the tailgate.
2) Move the lever (B) to push out on the tailgate to open it.
5. How to disconnect the 12V auxiliary battery negative terminal
Use an open end wrench (10 mm) to disconnect the negative terminal of the 12V auxiliary battery according
to the procedure below, and then wrap a plastic tape around the disconnected negative terminal.
Shut down the SRS air bag system circuit by disconnecting the negative terminal of the 12V auxiliary
battery.
1) Pull up the strap on the luggage floor box.
2) Remove the service lid of the 12V auxiliary battery.
3) Disconnect the 12V auxiliary battery negative terminal.
*: Refer to "10" for the explanation of pictogram
12V auxiliary battery
negative terminal
Electric tailgate
No Electric tailgate
Inside view
To Next Page
