13
4.Access to the occupants
Failure to follow these instructions when performing a rescue may result in serious injury such as electric shock.
Do not touch high voltage cable or components. Isolate high voltage circuits as necessary.
1. Windows
1 : Laminated glass
2 – 6 : Tempered glass
2. Adjustment seat and steering wheel
Seat
<Manual seat type> <Power seat type>
1 : To adjust forward or backward
2 : To recline the seatback
3 : To adjust seat height (driver’s side only)
1 : To adjust forward or backward
2 : To recline the seatback
3 : To adjust seat height
*: Refer to "10" for the explanation of pictogram
Use insulating Personal Protective Equipment (PPE) (Rubber insulating gloves, Rubber
soled insulating shoes: rated to a minimum of 400V voltage resistance) when you may
touch the vehicle body directly or indirectly.
CAUTION;
・When the 12V auxiliary battery is disconnected or removed, do not close the tailgate. If you close it once,
you cannot open it again.
・The electric tailgate system will also be inoperative when the 12V auxiliary battery is disconnected.
・The electric parking brake system will also be inoperative when the 12V auxiliary battery is disconnected.
To Next Page
