Mitsubishi Pajero Workshop Manual Supplement

CIRCUIT DIAGRAMS
3-3
MULTI-PURPOSE FUSE
Power supply circuit No. Rated capacity (A) Housing colour Load circuit
Ignition switch IG1 8 10 Red Combination meter, engine-A/T-ECU, engine-
ECU, ETACS-ECU, front propeller shaft speed
sensor, input shaft speed sensor, output shaft
speed sensor, SRS-ECU, transfer-ECU, rear
propeller shaft speed sensor and SC G sensor
J/B (in fuse box)
Multi-purpose fuse
