Mitsubishi Q03UD(E)CPU User Manual

4
I/O NUMBER ASSIGNMENT
4.8 Examples of I/O Number Assignment
4 - 31
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(b) I/O assignment with GX Developer
Designate slot No. 3 to "32 points" at the "I/O assignment" tab screen of GX
Developer.
(c) I/O number assignment after the I/O assignment with GX Developer
Figure 4.25 I/O assignment (When changing points of empty Slot 3)
Figure 4.26 I/O numbers after I/O assignment (After changing points of empty slot)
Select 32 points. (When
the type is not selected,
the type of the installed
module will be selected.)
Q38B
Q68B
Input module Input module Input module
Empty
Output module Output module Output module Output module
32
points
32
points
32
points
32
points
32
points
32
points
32
points
32
points
012 45673
X00 X20 X40 Y80 YA0 YC0 YE0
Number of I/O
points
Slot number
I/O number
60
X1F X3F X5F Y9F YBF YDF YFF7F
Intelligent function module Intelligent function module Intelligent function module Intelligent function module
Empty
Output module Output module Output module
32
points
32
points
32
points
16
points
32
points
32
points
32
points
32
points
8 9 10 12 13 14 1511
100 120 140 180 Y190 Y1B0 Y1D0160
11F 13F 15F 18F Y1AF Y1CF Y1EF17F
Extension 1
