6 - 164
6.21 LED Display
6.21.2 Priority setting
6
FUNCTIONS
(2) Priorities and factor Nos.
The description and default priority for the factor Nos. to be set in the special registers
SD207 to 209 are as follows:
* 1: The Basic model QCPU can set the priority only for the factor number 7 (annunciator).
* 2: Confirm the version of CPU module for actions to be taken in the High Performance model QCPU
and Process CPU. ( Appendix 4) The error message is not displayed in the Universal
model QCPU.
* 3: The error message is not displayed in the Basic model QCPU, High Performance model QCPU,
Process CPU, and Universal model QCPU.
* 4: The error message is not displayed in the Basic model QCPU, High Performance model QCPU,
Process CPU, and Redundant CPU.
* 5: Since the Redundant CPU and Universal model QCPU do not support low-speed execution type
programs, a low-speed execution monitoring timeout error does not occur.
* 6: The Basic model QCPU and Universal model QCPU do not support the CHK instruction.
Table6.42 List of default factor Nos. and priorities
Priority
Factor
number
*1
(Hexadecimal)
Displayed error message Remarks
11
AC/DC DOWN • Power shutoff
SINGLE PS.DOWN
*2
• Redundant base unit power supply voltage drop
SINGLE PS.ERROR
*2
• Redundant power supply module fault
22
UNIT VERIFY ERR.
FUSE BREAK OFF
SP.UNIT ERROR
SP.UNIT DOWN
• Module verification error
• Fuse shutoff
• Intelligent function module verify error
33
OPERATION ERROR
SFCP OPE.ERROR
SFCP EXE.ERROR
• Calculation error
• SFC instruction calculation error
• SFC program execution error
44
ICM.OPE.ERROR
FILE OPE.ERROR
• Memory card operation error
• File access error
OPE. MODE DIFF.
*3
• Operation status, switch mismatch
CAN'T EXE.MODE
*3
• Current mode-time function execution disabled
TRK.TRANS.ERR.
*3
• Tracking data transmission error
TRK.SIZE ERROR
*3
• Tracking capacity excess error
TRK.DISCONNECT
*3
• Tracking cable not connected, failure
FLASH ROM ERROR
*4
• Flash ROM access count over error
55
PRG.TIME OVER
• Constant scan setting timeout error
• Low-speed execution monitoring timeout error
*5
MULTI CPU ERROR • Other CPU error in the multiple CPU system configuration
66
CHK instruction
*6
--
7 7 Annunciator --
8 8 -- --
9 9 BATTERY ERROR --
10 A -- --
11 B
CAN'T SWITCH
*3
• System switching error
STANDBY SYS.DOWN
*3
• Standby system not started/stop error
MEM.COPY EXE.
*3
• Memory copy function executed
