App - 5 App - 5
MELSEC-Q
A
PPENDI
X
(b) PCWT command
Processing codes used in the A1SD51S/AD51H-S3
Contents Processing Code
Treatment
Device memory monitor registration 2(&H2)
Random writing to device memory 3(&H3)
Writing to expansion file register 4(&H4)
Expansion file register monitor registration 5(&H5)
Random writing to expansion file register 6(&H6)
Continuous address designation data writing
to expansion file register
7(&H7)
Writing to Q/QnA series device memory
Processing Code 515 (&H203)
Writing of sequence program 8(&H8)
Writing of microcomputer program 9(&H9)
Writing of comment data 10(&HA)
Writing of expansion comment data 11(&HB)
Cannot be used in the Q/QnA Series
Cannot be replaced
Writing to special function module buffer
memory
12(&HC)
Writing to Q/QnA series intelligent function
module buffer memory
Processing code 533 (&H215)
Writing of parameter data
(Writing of MELSECNET/10 parameters)
14(&HE)
Analysis of parameter data 15(&HF)
Cannot be used in the Q/QnA Series
Cannot be replaced
(7) Year of DATE$
The year setting of DATE$ varies.
A1SD51S/AD51H-S3 QD51(-R24) Countermeasure
Reading Reads only the last two digits of the year.
However, if the last two digits are 90 or
more, the first two digits are 19. If the last
two digits are less than 90, the first two
digits are 20.
Reads the four-digit
year as it is.
Modify the program to
use four-digit year
processing.
Writing Writes only the last two digits of the year. Writes the four-digit
year as it is.
Designate the year as
four digits correctly.
