2 - 3 2 - 3
MELSEC-Q
2 SYSTEM CONFIGURATION AND USABLE FUNCTIONS
(3) Applicable Software Package
The following software package supports the QD51 (-R24)
(a) Console/debugger software package (essential)
Product Name Model Name Remarks
AD51H-BASIC Software Package SW1IVD-AD51HP-E For PC/AT Personal Computers
CAUTION
To use SW1IVD-AD51HP-E on Microsoft
R
Windows
R
95 Operating System or
Microsoft
R
Windows
R
98 Operating System, operate it in the MS-DOS
R
mode.
Do not operate on the MS-DOS
R
prompt screen of Windows
R
95/Windows
R
98.
It will not run correctly.
(b) Software package for programmable controllers (Essential)
Software version
GX Developer
Single CPU system Version 7 or later
Q00J/Q00/Q001CPU
Multiple CPU system Version 8 or later
Single CPU system Version 4 or later
Q02/Q02H/Q06H/Q12H/Q25HCPU
Multiple CPU system Version 6 or later
Single CPU system
Q02PH/Q06PHCPU
Multiple CPU system
Version 8.68W or later
Single CPU system
Q12PH/Q25PHCPU
Multiple CPU system
Version 7.10L or later
Q12PRH/Q25PRHCPU Redundant system Version 8.45X or later
Single CPU system
Q02U/Q03UD/Q04UDH/Q06UDHCPU
Multiple CPU system
Version 8.48A or later
Single CPU system
Q13UDH/Q26UDHCPU
Multiple CPU system
Version 8.62Q or later
Single CPU system Q03UDE/Q04UDEH/Q06UDEH/
Q13UDEH/Q26UDEHCPU
Multiple CPU system
Version 8.68W or later
When installing to a MELSECNET/H remote I/O station Version 6 or later
(c) Commercially available compilation software package (necessary only for
compilation)
When using a PC/AT personal computer
Purchase the product Turdo Assembler 5.0.
For Turbo Assembler, contact Borland Software Corporation.
Product Name Model Name Remarks
Turbo Assembler Turbo Assembler Ver.5.0 IBM PC/AT English Version
(4) Connection Cable for Console/Debugger
Refer to Section 5.4 for connection to a console.
