2 - 9 2 - 9
MELSEC-Q
2 SYSTEM CONFIGURATION AND USABLE FUNCTIONS
REMARK
For QnA/A Series MELSECNET/10 remote I/O stations, only reading from and
writing to the intelligent function module's buffer memory can be done.
(3) Setting from GX Developer
In the case of mounting the QD51(-R24) on a MELSECNET/H remote I/O station,
set the following parameters in GX Developer.
Each setting method is the same as the parameter setting for the QD51(-R24)
installed to the QCPU station. Refer to Section 5.6 and subsequent sections.
For the method for displaying each setting screen, refer to the GX Developer
Operating Manual.
(Parameter setting sections for the QD51 (-R24) when installed to a
MELSECNET/H remote I/O station)
Parameter Setting Item Setting Remarks
I/O Assignment Sets the module installation information. Refer to Section 5.6.1.
Switch setting for I/O and intelligent
function modules
Sets the transmission specifications and
communications protocol for with other
devices, etc.
Refer to Section 5.6.2.
POINT
(1) Connect GX Developer to the MELSECNET/H remote I/O station and set the
parameters.
(2) After changing the settings, reset the MELSECNET/H remote I/O station.
To Next Page
