MELSEC-Q
APPENDICES
(2) 37-pi
n D-sub connectors
(a)
A6CON1E sol
dering type 37-pin D
sub-connector
(straig
ht out type)
A6CON2E crimp-
contact-type 37-pin D sub-connector
(straig
ht out type)
Uni
t: mm
(b) A6CON
3E pressure-displacement ty
pe 37-pin D-sub connector
(flat cable ty
pe)
Uni
t: mm
3.4
5.9
69.4
12.6
147
149
