Mitsubishi SCM100ZJ-S1 User Manual

-
244
-
'11 • SCM-SM-110
＜SUB PCB: PCB4＞
Connector Connected to Normal value Remark
CNEEV1
EEV A(WH) and EEV B(RD)
CNEEV2
EEV C(BL) and EEV D(GN)
CNEEV3
EEV E(BL)
CNEEV4
EEV F(YE)
CNS2 CNS1 on PCB 1 13VDC
CNX2 CNX1 on PCB 1
Signal of SL
※1
※1
※1
※1
※1
※1
※1
※2
※2
CNF
For inddor unit (125 only)
CNE For indoor unit
CND For indoor unit
CNC For indoor unit
CNB For indoor unit
CNA For indoor unit
CNDRM TB8
CNTRO 30VAC
CNTRI 0-21VDC
L.IN - N.IN 220-240VAC
＜SUB PCB: PCB5＞
Connector Connected to Normal value Remark
TB3 TB1(L)
TB4 TB2(N)
TB5 CNW on PCB1,TB3 on PCB3
TB6 CNW on PCB1,TB4 on PCB3
TB7 Earth
220-240VAC
220-240VAC
CNA
(RD)
CNB
(BR)
CND
(YE)
CNE
(OR)
CNF
(PK)
CNC
(BL)
CNS2
CNX2
CNDRM
CNTRI
CNTRO
CNEEV4
CNEEV2
CNEEV3
CNEEV1
N, IN
L, IN
TB5
TB6
TB4
TB3
TB7
