Mitsubishi SCM45ZS-S User Manual

-
320
-
'16 • SCM-T-199
PJZ012D076
This manual contains installation points and operating instructions for the filter kit manufactured by MHI.
Carry out the work following the instructions below.
This manual also contains information on the usage after installation,
so keep this manual properly with USER’S MANUAL provided with the indoor unit.
・
After unpacking
,
carry out this work on the ground
.
・Do not carry out the work during operation, or there is a danger of being entangled in the rotating
parts and getting injured.
・
Clean the air filter regularly
.
・Be sure to entrust qualified serviceman to performance on the air filter.
・Be sure to cut off the power and stop the unit before performing maintenance.
1
. Table of filter kit parts No. and corresponding object models
Small model
Medium model
Large model
Single type 50 60, 71 100 - 140
Multi type 22 - 56 71, 90 112 - 160
Filter Kit UM-FL1EF UM-FL2EF UM-FL3EF
2
. Parts list of filter kit
Filter Rail Insulation
1pc 2pc 2pc
Bracket Parts set (screw)
small and medium-sized large model : 7pcs.
model : 5pcs.
1pc 1pc
Installation Points and Operating
Instructions for the Filter Kit
! CAUTION
PJZ012D076A
PJZ012D076
This manual contains installation points and operating instructions for the filter kit manufactured by MHI.
Carry out the work following the instructions below.
This manual also contains information on the usage after installation,
so keep this manual properly with USER’S MANUAL provided with the indoor unit.
・
After unpacking
,
carry out this work on the ground
.
・Do not carry out the work during operation, or there is a danger of being entangled in the rotating
parts and getting injured.
・
Clean the air filter regularly
.
・Be sure to entrust qualified serviceman to performance on the air filter.
・Be sure to cut off the power and stop the unit before performing maintenance.
