Mitsubishi SKM32ZA User Manual

66
Model SRRM40ZA
• Details of air outlet
ø 4 × 8 (Holes for tapping screws)
Air outlet
Air inlet
540 100100
105 220 90 220 105
150 3050
170 2040
320
35
670 (Suspension bolts pitch)
740
35
107
Suspension bolts (M8 × 4)
(Procured by customer)
Controller
243
3030
515 (Suspension bolts pitch)
455
60
16
117
150
230
Air outlet
Terminal block
[I]
38
135 75
Gas piping (ø 12.7)
Liquid piping (ø 6.35)Drain hose
(Connection opening diameter ø 16)
Unit: mm
