Mitsubishi SRK Series

-
29
-
'18 • SRK-T-250
Condition
Model SRK20ZS-W,WB,WT
N
oise Cooling 34 dB(A)
M
ODE
Level Heating 36 dB(A)
× Cooling ○ Heating
Model SRC20ZS-W
N
oise Cooling 45 dB(A)
L
evel Heating 45 dB(A)
× Cooling ○ Heating
ISO5151 T1/H1
10
20
30
40
50
60
70
10
20
30
40
50
60
70
10
20
30
40
50
60
70
10
20
30
40
50
60
70
63 125 250 500 1000 2000 4000 8000
63 125 250 500 1000 2000 4000 8000
Sound pressure level (dB)
(Standard 2x10
-5
Pa)
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2x10
-5
Pa)
Mid octave band frequency (Hz)
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
N50
N30
N40
N60
N70
N20
N50
N30
N40
N60
N70
N20
Rated capacity value
（Indoor unit）
（Outdoor unit）
(2) Sound pressure level
(a) Rated capacity value
Model SRK20ZS-W, -WB, -WT
