Mitsubishi SRK10CFV-4; SRK13CFV-4 User Manual

SRC10CFV-4
END ITEM NO. : RWC003F056D
Recommendable Purchased Q't
y
10 30 50 100 500 1000
1 RCS 122A 500 PANEL ASSY,FRONT 1 1112
2 RCS 123A 001 PANEL,SIDE(R) 1 1112
3 RCS 132A 001 PANEL,SERVICE 1 1124
4 RCS 435A 002A GRILL ASSY,AIR OUT 1 1123
5 SSA 944B 036 HANDLE 1
6 SSA 913A 034B SCREW,TAP 17 4×8
7 SSA 913A 034C SCREW,TAP 3 4×12
8 RCS 124A 500 PANEL ASSY,TOP 1 1112
9 RCS 116A 006 BRACKET ASSY 1
10 SSA 511J 221 MOTOR,AC 1 2248
11 RCS 141A 500 PLATE,BAFFLE 1
12 SSA 431B 213 PROPELLER 1 1124
13 RSA 914B 002 NUT,FLANGE 1
14 RCS 111A 001D BASE ASSY 1 1112
15 RSA 011H 016A LABEL,NOTICE 1
16 RCS 116A 502 BRACKET 1
17 W011D04X008 TAP-SCREW,CRS-TRS 2 4 4×8
18 D100X20X036R INSULATION 1
NoteNo. Part No. Part Name RE.Q
- 42 -
