Mitsubishi SRK13CES User Manual

SRK13ZEV-S
END ITEM NO. : RMA002F004
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-4 RKT102A750B PANEL ASSY,FRONT 1 1112
1 RKT122A600B PANEL,FRONT 1 1112
2 RKT435A600C PANEL AIR, INLET 1 1123
3 RKT435A601 GRILLE, AIR IN (TOP) 2 1123
4 RKT437A600 FILTER,AIR 2 2248
5 RKT129A607 HOLDER,FILTER 2 1112
6 RKT132A500B LID ASSY 1 1112
7-20 RKT435A602C GRILLE ASSY,AIR OUT 1 1123
7 RKT435A401B GRILLE,AIR OUTLET 1 1123
8 RKT436A400B FLAP(A) 1 1122Upper
9 RKT436A401B FLAP(B) 1 1122Lower
10-11 RKT436A410B LOUVER ASSY 2 1122
10 RKT436A403B LOUVER 6 1122
11 RKT129A413B PLATE,CONNECTING 1 1112
12 RKR935C001B COLLAR 6
13 RKT144A400 CRANK(A) 1 1112
14 RKT144A401 CRANK(B) 1 1112
15 RKT144A402 LINK 1 1112
16 RKT129A404 BRACKET, MOTOR 1 1112
17 SSA512T049 MOTOR,STEPPING 1 1112
18 RKS504A100A HARNESS ASSY 1 1112For Flap Motor
19 SSA423A094 HOSE,DRAIN 1
20 SSA326A041 PLUG 1
21 RKT111A500D BASE ASSY 1 1112
22 SSA512T046A MOTOR,DC 1 1112For Impeller
23 SSA431G040 IMPELLER 1 1 1 2 4
24 SSA923C114 BEARING,PLANE 1 1112
25 RKT129A400 COVER (MOTOR) 1 1112
26 SSA913A007A SCREW,TAP 2
27 RKT032A400A PLATE,INSTALLATION 1 1112
28 RKT132A401B LID(R) 1 1124
29 RKT132A402B LID(L) 1 1124
No. Part NO. NotePart Name RE.Q
- 205 -
