'18 • SRK-T-234
-
33
-
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
Model SRK25ZSX-W
, -WB, -WT
(Indoor Unit)
Model SRK25ZSX-W, -WB, -WT
Noise
Level
Cooling 39 dB(A)
Heating 40 dB(A)
×
......
Cooling,
Heating
(Outdoor Unit)
Model SRC25ZSX-W
Noise
Level
Cooling 44 dB(A)
Heating 45 dB(A)
×
......
Cooling,
Heating
Condition ISO5151 T1/H1
MODE Rated capacity value (Hi)
70
60
50
40
30
20
10
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
N50
N30
N40
N60
N70
N20
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10
-5
Pa)
70
60
50
40
30
20
10
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
N50
N30
N40
N60
N70
N20
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10
-5
Pa)
