'18 • SRK-T-234
-
34
-
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
Mike position: at highest noise level in position as mentioned below
Distance from front side 1m
Mike position
0.8m
1m
Unit
Mike position
(Center & low points)
Model SRK35ZSX-W
, -WB, -WT
Condition ISO5151 T1/H1
MODE Rated capacity value (Hi)
(Indoor Unit)
Model SRK35ZSX-W, -WB, -WT
Noise
Level
Cooling 43 dB(A)
Heating 42 dB(A)
×
......
Cooling,
Heating
(Outdoor Unit)
Model SRC35ZSX-W
Noise
Level
Cooling 48 dB(A)
Heating 47 dB(A)
×
......
Cooling,
Heating
70
60
50
40
30
20
10
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
N50
N30
N40
N60
N70
N20
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10
-5
Pa)
70
60
50
40
30
20
10
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
N50
N30
N40
N60
N70
N20
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10
-5
Pa)
