– 7 –
Name of each part and its function
Air inlet panel Air inlet
Air filters
Air outlet
Air outlet
Room temperature
sensor
Heat exchanger
(Aluminum fin)
Heat exchanger
(Aluminum fin)
Fan
• Inside of
the unit
Louvers
(Vertical blades)
• Left / right airflow
direction adjustment
Flaps
(Horizontal blades)
• Up / down airflow
direction adjustment
Page 30, 31
Page 30
OUTDOOR UNIT
INDOOR UNIT
Air-cleaning filter
Page 32
• Allergen clear filter
(Light orange)
• Photocatalytic washable
deodorizing filter (Orange)
Air inlet
(back and side)
Fan
• Inside of the unit
Model name
Refrigerant pipe
and electric wire
Drain hose
Drain hole
IT MIGHT CAUSE INJURY.
DO NOT STEP ON TOP OF THIS UNIT.
WARNING
DO NOT INSERT ANYTHING
INTO THE AIR OUTLET.
IT MIGHT CAUSE INJURY.
DO NOT TOUCH THE
ALUMINUM FINS.
IT MIGHT CAUSE INJURY.
SHARP EDGE OF FINSMOVING FAN BLADES
CAUTION
Don't touch
the terminal
Don't touch
refrigerant
pipings and
connections.
block.
Model name
Unit display
section
Page 8
SPLIT TYPE
MODEL
SERVICE CODE
POWER SUPPLY
( INDOOR UNIT )
Motion
sensor
Model name label
(SRC50-60ZSXA-W)
Model name label
(SRC20-35ZSXA-W)
DO NOT INSERT ANYTHING
INTO THE AIR OUTLET
WARNING
* This equipment uses
flammable refrigerant.
Page 2
* This equipment
uses flammable
refrigerant.
Page 2
*This label is for only R32 models.
