Mitsubishi SRK21CNS-S6

-
49
-
'14•SRK-T-164
SRK21CNS-S6
END ITEM NO. : RMA002F062AH
10 30 50 100 500 1000
1㹼7 RMA 102A 101C PANEL ASSY,FRONT 1 1 1 1 2
1 RKY 122A 002B PANEL ASSY,FRONT 1 1 1 1 2
2 RKY 435A 003 GRILLE,AIR IN(TOP) 2 1 1 2 3
3 RMA 435A 010D PANEL ASSY,AIR IN 1 1 1 2 3
4 RKY 437A 001 FILTER,AIR 2 2 2 4 8 W348.5×H339(t2)
5 RKY 129A 012 CAP 2 1 1 1 2
6 RKY 133A 008C PLATE ASSY,ORNAMENT 1 1 1 1 2
7 RMA 011G 007 LABEL WIRING 1
8㹼29 RMA 435A 009C GRILLE ASSY,AIR OUT 1 1 1 2 3
8 RKY 435A 002 GRILLE,AIR OUT 1 1 1 2 3
9 RMA 436A 001 FLAP ASSY(U) 1 1 1 2 2 UPPER
10 RMA 436A 003 FLAP ASSY(L) 1 1 1 2 2 LOWER
11࣭12 RKY 436A 009 LOUVER ASSY 1 1 1 2 2
11 RKY 436A 011 LOUVER 6 1 1 2 2
12 RKY 129A 011 PLATE,CONNECTING 1 1 1 1 2
13࣭14 RKY 436A 009A LOUVER ASSY 1 1 1 2 2
13 RKY 436A 011 LOUVER 6 1 1 2 2
14 RKY 129A 011 PLATE,CONNECTING 1 1 1 1 2
15 RKW 935C 200 COLLAR 4
16㹼22 RKY 144A 010 LINK ASSY(R) 1 1 1 1 2
16 RKY 129A 009 JOINT(R) 1 1 1 1 2
17 RKY 129A 005 BRACKET,MOTOR(R) 1 1 1 1 2
18 RKY 144A 001 LINK 1 1 1 1 2
19 RKY 144A 002 CRANK(A) 1 1 1 1 2
20 RKY 144A 003 CRANK(B) 1 1 1 1 2
21 RKY 144A 004 CRANK(C) 1 1 1 1 2
22 SSA 512T 096 MOTOR,STEPPING 2 1 1 1 2
FOR LOUVER(RIGHT),FLAP
23㹼26 RKY 144A 011A LINK ASSY(L) 1 1 1 1 2
23 RKY 129A 010 JOINT(L) 1 1 1 1 2
24 RKY 129A 006 BRACKET,MOTOR(L) 1 1 1 1 2
25 RKY 144A 004 CRANK(C) 1 1 1 1 2
26 SSA 512T 096 MOTOR,STEPPING 1 1 1 1 2 FOR LOUVER(LEFT)
27 RMA 504A 013 HARNESS ASSY 1 1 1 1 2
28 SSA 423A 102 HOSE,DRAIN 1
29 SSA 326A 047 PLUG 1
30 RKY 111A 001A BASE ASSY 1 1 1 1 2
31 RKY 129A 002A PLATE,BASE 1 1 1 1 2
32 RKY 129A 037 BRACKET ASSY(U) 1 1 1 1 2
33 RKY 129A 038 BRACKET ASSY(L) 1 1 1 1 2
34 SSA 923C 114 BEARING,PLANE 1 1 1 1 2
35 SSA 431G 050A IMPELLER 1 1 1 2 4
36 SSA 512T 127A MOTOR,DC 1 1 1 1 2 FOR IMPELLER
37 RKY 032A 001 PLATE,INSTALLATION 1 1 1 1 2
No. Part No. Part Name
RE.Q
Recommendable Purchased Q'ty
Note
