Mitsubishi SRK21CNS-S6

-
59
-
'14•SRK-T-164
CRAE0290
28
25
30
29
33
26
32
31
14
27
15
2
5
6
7
9
8
10
4
17
21
20
19
18
22
24
23
1
3
13
12
11
16
HEAT EXCH. & CONTROL
SRK26CNS-S6
END ITEM NO. : RMA002F063AH
10 30 50 100 500 1000
1㹼10 RMA 301A 008 HEAT EXCH ASSY(AIR) 1 1 1 1 2
2 RMA 315D 003 HEADER ASSY 1
3 RKW 129A 410 BRACKET ASSY(L) 1 1 1 1 2
4㹼10 RMA 315A 006 DISTRIBUTOR ASSY 1
4 RSA 315A 005 DISTRIBUTOR 1
5 RMA 321A 015 PIPE ASSY 1
䃅 2.8×ĭ 4.0 L100
6 RMA 315B 004 CAPILLARY 1
䃅 2.8×ĭ 4.0 L100
7 RMA 315B 005 CAPILLARY 1
䃅 2.8×ĭ 4.0 L100
8 RMA 321A 016 PIPE ASSY 1
䃅 2.8×ĭ 4.0 L100
9 RMA 321A 018 PIPE ASSY 1
䃅 2.8×ĭ 4.0 L100
10 RMA 321A 020 PIPE ASSY 1
䃅 2.8×ĭ 4.0 L100
11㹼13 RMA 321A 030 PIPE ASSY 1
12 SSA 323F 012F UNION,SOLDER 1 FOR GAS
13 SSA 323F 088A UNION(SLD) 1 FOR LIQ.
14 RKW 129A 411 HOLDER ASSY,FILTER 1
15࣭16 RKW 142A 400 BOX ASSY,CONTROL(R) 1
15 RKW 142A 402 BOX,CONTROL(R) 1
16 RKW 132A 404 COVER,CONTROL(R) 1
17 RKW 142A 401 BOX ASSY,CONTROL(L) 1
18 RKW 129A 407 HOLDER,SENSOR 1
19 SSA 551A 223H SENSOR ASSY 1 1 1 2 4
INCL.SENSOR (ROOM TEMP.& HEAT EXCH.)
20 SSA 551B 017C SENSOR(HUMIDITY) 1 1 1 2 4
21 SSA 561B 702B BLOCK,TERMINAL 1 1 1 2 2 T1
22㹼24
RKY 505A 001JL
PWB ASSY 1 2 2 4 8
23
SSA 555B 058AD
VARISTOR 1 1 1 1 2 Z
24 SSA 564A 132 FUSE(CURRENT) 1 1 1 1 2 F 3.15A
25
RKW 503A 400A
DISPLAY ASSY 1 1 1 2 4
26
RKW 505A 400A
PWB ASSY(DISPLAY) 1 2 2 4 8
27 RKJ 941F 001A SPRING,LEAF 1
28
RMA 008A 016B
PARTS,STANDARD 1
29 RKX 502A 001 CONTROL ASSY,REMOTE 1 2 3 5 10
30 RMA 012A 078 MANUAL,INSTRUCTION 1
31࣭32
RKW 437A 201A
FILTER ASSY,CLEAN 1
31 RKT 437A 005D FILTER,LIGHT CLEAN 1
32 RKT 437A 011D FILTER,CLEAN 1
33
RKN 032A 002C
HOLDER(REMO-CON) 1 1 1 1 2
(34)
RMA 011F 016BG
LABEL,MODEL NAME 1
NoteNo. Part No. Part Name
RE.Q
Recommendable Purchased Q'ty
