EN-11
AUTO mode operation
■ Automatically selects the operation mode (COOL, HEAT, DRY) depending on the room temperature when switched on.
x If you do not want the AUTO mode program,
change to COOL, HEAT or FAN instead of
AUTO.
Page 12
x Airflow direction adjustment procedure.
Page 13
To stop: Press the ON/OFF button.
Press the MODE button.
The mode changes whenever the button is pressed.
Set to
.
Press the ON/OFF button.
Press the
or button.
Default preset temperature during AUTO mode is 24 °C for both cooling and
heating mode. However, it can be adjusted (Minimum 18 °C, Maximum 30 °C)
using
button or button.
1
3
2
FAN SPEED
■ The FAN SPEED can be set except for DRY mode.
Press the FAN SPEED button.
Each time the button is pressed, the fan speed changes.
1
x When FAN SPEED is changed from HI to LO, the sound of refrigerant
may be heard.
x When COOL mode is used if outside temperatures are low, the FAN
SPEED may change automatically to protect the air-conditioner.
NOTE
Operation capacity by your choice FAN SPEED
Set automatically by microcomputer AUTO
Powerful operation with high capacity
HI
Standard operation MED
Energy-saving operation
LO
■
Each time the button is pressed, the switch over occurs in the following order
–6 o –5 o ............ –1 o ±0 o +1 ............ +6.
When +6 is indicated, even if the button is pressed, the indicator does not change.
■
Each time the button is pressed, the switch over occurs in the following order
+6 o +5 o ............ +1 o ±0 o –1 ............ –6.
When –6 is indicated, even if the button is pressed, the indicator does not change.
When it is a little cold
Press the
button.
When it is a little hot
Press the
button.
Remote Control display
-6 -5 -4 -3 -2 -1
+
0 +1 +2 +3 +4 +5 +6
18 19 20 21 22 23 24 25 26 27 28 29 30
Setting
temp.(
°C
)
x In case air is not blowing out during the
operation.
Page 22
NOTE
AUTO HI MED LO
