TC0169eMITSUBISHI TRITON 3 PIECE TONNEAU COVER
29/10/10Page 13 of 13
ISSUE05
1 25
10
16
Tonneau Cover
Qty - 1
PARTS IN MAIN CARTON
Lock Keys
(Attached to
Tonneau)
Qty - 2
3
RHS Corner
Piece
Qty - 1
2
LHS Corner
Piece
Qty - 1
Fitting Kit
(KIT031386)
Qty - 1
5 6 7 8 9
A
B
Gas Strut
Bracket
(CLIP2034-1)
Qty - 2
Hinge Pin
(MISC2267)
Qty - 2
M6x15 Hex
Head Bolt
(SCRW0633)
Qty - 8
M6 Flat
Washer
(WASH0153)
Qty - 24
M6Hex Nut
(NUTS0161)
Qty - 16
Pop Rivet
(FAST0505)
Qty - 12
11 12 13 14 15
21
Bottom Hinge
(CLIP1805-1)
Qty - 2
Hinge Retainer
Clip
(CLIP2673)
Qty - 2
Gas Strut
(STRT0003-2)
Qty - 2
M8x50 Hex
Head Bolt
(SCRW0789)
Qty - 2
M8Hex Nut
(NUTS0217)
Qty - 4
Jacking
Bracket
(CLIP2353-3)
Qty - 2
Extrusion
Tape Roll
(MISC2600)
Qty - 1
M6 Large
Flat Washer
(WASH0036)
Qty - 4
Striker U-Bolt
(LOCK0006)
Qty - 2
Lock Striker
Support Bracket
(CLIP2613PC)
Qty - 2
PARTS IN FITTING KIT (KIT031386)
17 18 19 20
M6 Spring
Washer
(WASH0103)
Qty - 12
PARTS CHECK SHEET MITSUBISHI TRITON 3 PIECE HARD TONNEAU COVER
4
Lock Striker
Bracket
(CLIP2499-PC)
Qty - 2
AUTOMOTIVE
SURFACE CLEANER
IMPREGNATED WITH 70% ISOPROPYL ALCOHOL
For use in cleaning painted metal,
glass and other vehicle surfaces.
For external use only.
Dispose of properly after use.
22 28
Rust Inhibitor
(MISC2776)
Qty - 1
Alcohol Wipe
(MISC0052)
Qty - 4
M6x40 Allen
Key Bolt
(SCRW0517)
Qty - 4
Anti-Rub Pad
(TAPE0011)
Qty - 2
Rubber
Thread Cap
(MISC2532)
Qty - 4
Fitting Instruction
(FIT-TC0169)
Qty - 1
23 24 26 27
Spacer
(MISC3095)
Qty - 4
Fitting
Instructions
