5
BUTTON DEFINITION
C300S has three buttons, including MODE、UP and DOWN.
“MODE” names to “M”, “UP” names to “＋” and “DOWN” names to “－”.
NORMAL OPERATION
1、MODE
Hold MODE and start the display. The display will provide power for the controller.
Hold MODE again can open the backlight. With display on, press MODE for 1.5
seconds to turn off the power. With the display off, there is no battery consumption.
The leakage current is no more than 2 µA.
※ The panel will go to sleep when speed is less than 2 km/h for 5 minutes.
2
、
CURRENT DISPLAY
That represents the discharging current of the controller currently, each segment is 2A,
six segments are >=12A.
