MKS DLC32 - Laser;Spindle 2-Pin Connection; LCD and Expansion Ports

5
LASER-2PIN/CNC
LCD PART
G:GND
S:PWM (PWM signal, 0-12V OR 0-24V)
NOTE: If the laser/cnc directly loaded by the
motherboard, it is recommended that the current
should not exceed 2A
If more power is required, it is recommended to
supply additional power to the load
