Mobiclinic MULTIFIT - Page 13

Pull-up station
MULTIFIT
ENES FR
IT DE
PT
NL
SWE
PL DK
13
Step 5.
Connect the back cushion (J) and the rear tube (F) with the screws (d) (M8*14).
Step 6.
Place the straight side of the adjustable tubes (G) on the main tube (B), use the adjustable screws (a) to
choose the right height. Finally, connect the handlebars (H) and the adjustable tubes (G) with the 2 sets of
screws of the combination (i) - Screw (M8*65) + Washer (M8) + Nut (M8).
J
d
i
H
G
a
