Sheet 6 of 8
Negative Grounded System
I. ConnecttheREDCLAMP(positive+)tothepositiveterminalof
the vehicle battery or the remote positive terminal if available.
II. Connect the BLACK CLAMP (negative -) to the vehicle engine
block, or a metal part of the vehicle which is connected to the
vehicle main ground system. Do not clamp directly to negative
battery terminal, main fuel distribution module or sheet metal
parts.
MAKE SURE THE BATTERY POLARITY CONNECTIONS ARE
CORRECT.
Positive Grounded System:
I. ConnecttheBLACKCLAMP(negative-)tothenegativeterminal
of the vehicle battery.
II. ConnecttheREDCLAMP(positive+)tothevehicleengineblock,
or a metal part of the vehicle which is connected to the vehicle
ground system. Do not clamp directly to positive battery terminal,
main fuel distribution module or sheet metal parts.
MAKE SURE THE BATTERY POLARITY CONNECTIONS ARE
CORRECT.
7. Allow3to5minutes ofchargetime.It ishighlyrecommended
having a second person to assist holding the unit securely in
placeduringthenextsteps.
8. Startthe engine. Stopif the vehicledoes not startafter 2 to3
secondsofenginecranking.Wait2to3minutesthentryagain.
Repeat the above steps several times until the vehicle starts.
9. If the vehicle starts, disconnect the clamps as far away from the
vehicle battery as possible.
For Negative Grounded System, disconnect the BLACK CLAMP
Negative first and then the RED CLAMP Positive.
For Positive Grounded System, disconnect the RED CLAMP
Positive first, and then the BLACK CLAMP Negative.
10. Stow the booster clamps into their storage compartment located
on sides of the Spotlight.
CHARGING INSTRUCTIONS:
CAUTIONS
• Priortochargingthisdevicereadandunderstandalltherelated
instruction indicated below. This product may arrive partially
charged from the factory. It is highly recommended to fully charge
the unit after purchase and before initial use.
