MobileVision M115C User Manual

5
General Operation
Mode Adjustment
To access the monitor display ratio menu, press the
remote’s MODE SELECT button.
MENU
MODE
SELECT
MENU
MODE
SELECT
To adjust the display ratio, press the MODE SELECT
button on the remote. After adjustment has been made
wait 6 seconds and the pop-up menu will disappear.
Technical Specifications
• 7” TFT-LCD color monitor
• Audio output: 1 watt
• Rear speaker
• Power supply: automobile storage
battery (8-16VDC)
• Power consumption: about 10 watts
• Outer dimension:
Without Flush Mount
181mm (W) x 121mm (H) x 28mm (D)
With Flush Mount
205mm (W) x 146mm (H) x 28mm (D)
• Dot pitch: 0.321 (W) x 0.372 (H)
• Resolution: 480 x 3 (RGB) x 234
• Contrast: 250:1
• Brightness: 450cd/m
2
• Viewing angle: U: 30 / D: 60, R/L: 60
•
Operating temperature: -20 ~ +70
O
C, RH90%
• Storage temperature: -30 ~ +80
O
C, RH90%
