MobileVision M115C User Manual

7
Flush Mounting the Monitor
1. Locate a suitable location for mounting the monitor (In-Dash, In-Wall, Headrest, etc.) .
Then cut a 7-1/2" (W) x 5" (H) opening and insert and secure the flush-mount housing.
2. After securing the housing, insert the monitor into the housing. Do Not Apply Pressure
Directly to the LCD Monitor’s Screen. Utilize the outer edges to gently push the monitor
into the housing until it snaps into place.
Installation Instructions
Removing the Flush Mounted Monitor
1. Press the release buttons on the housing. The screen will be release from the mount.
2.
Remove the monitor .
“Snap”
“Snap”
Mounting Screws
(Not Supplied)
Cut a 7
1
/2" x 5"
Opening
Do Not
Press on Screen
Do Not
Press on Screen

MobileVision M115C Specifications

General

Brand	MobileVision
Model	M115C
Category	Monitor
Language	English
