MobileVision MV100 - Extender Wireless Housing Mount; Mounting and Caulking

13
2) Screw the Extender Housing Bottom Mount to roof with Self Tapping Screws (#8).
1) Center the Extender Housing Bottom Mount over drilled hole.
Caulk the Extender Housing Bottom Mount on 1st Level (shown in orange area).
WARNING - Do not caulk on the 2nd Level (where the Top
Mount connects to the Extender Housing Bottom Mount).
Bottom
Mount
Self
Tapping
Screws #8
RV
Roof
1st Level
Caulking Area
Represented in
Orange
2nd Level
