progressive music system
Instruction for system connection
1. Connect the Woofer, Front Left/Right, Center, Rear Left/Right Speaker Cables to the appro-
priate Audio Output Sockets on the back of the Ampli er
2. Connect one end of the 2RCA-2RCA Signal Cable to the appropriate 5.1 Input Socket
of the Front Left/Right, Center & Rear Left/Right Channel on the back of the Ampli er, the
other end to the appropriate Audio Output Sockets on the DVD
3. If connect any 2-channel source, just connect one end of the 2RCA-2RCA Signal Cable to
the R/L AUX Input Socket on the back of the Ampli er
4. If connect to PC soundcard or any source only with headset output, then please use the
2RCA-3.5mm Signal Cable
5. Make sure all the cables are connected correctly, connect the power plug to the correct
AC outlet
Remarks
for the system positioning:
• The satellite speakers of this system are magnetically shielded which enables to place them
next to PC monitor or near the TV
• The woofer is recommended to be put on the  oor to get a better acoustic e ect
• The satellite speakers and the woofer should be positioned  rmly to avoid resonance
Operating instruction:
1. Manual Operating of front panel controls
a. Press the Power Button to turn on the power and the “POWER” indicator is lightened, the
system is under stand-by mode
b. Turn the “Master Volume” knob to turn o the “POWER” indicator, the 5.1CH indicator is
lightened, the digital LED displays 5.1 channel volume at 40dB, refer to the Drawing on the
right side
c. Press the “INPUT SEL” (input selection) button to turn on the “AUX” indicator, the digital
LED displays “2.0”
d. Turn the “Master Volume” knob to adjust the volume
2. Operation of the remote control
a. Press the Power Button to turn on the power, the “POWER” indicator is lightened, the sys-
tem is under standby mode
b. Press the “ST-BY” button to turn on the DVD indicator, the digital LED displays “5.1”
c. Press the “INPUT SEL” button to select between the 2.0 and 5.1 input mode
d. Press the Volume +/- button to increase/decrease the volume from 0 to 80dB
