VOLCANO
INPUT – VOLCANO 850W
Voltage
Minimum Nominal Maximum Units
90 115~230 264 Vrms
FREQUENCY 47Hz ~ 63Hz
CURRENT 115Vac / 12.0A max. 230Vac / 6A max.
INRUSH CURRENT
55A max. when AC input 115Vac at 25°C cold start.
110A max. when AC input 230Vac at 25°C cold start.
POWER EFFICIENCY 80% (min.) at full load(typical) and 115Vac input.
LEAKAGE CURRENT 3.5mA max.
POWER FACTOR PF > 0.9
HOLD-UP TIME 16msec (minimum) at 80% of full load at 230Vac input.
OPERATING TEMP. 10
o
C to +50 °C
STORAGE TEMP. -20
o
C to +70 °C
OPERATING HUMIDITY 20% to 90%,non-condensing
STORAGE HUMIDITY 5% to 95%, non-condensing
OPERATING ALTITUDE 0 to 10,000 feet
STORAGE ALTITUDE 0 to 50,000 feet
MTBF at 25° C: 100 000 hrs minimum
DIMENSIONS WxLxH: Power Supply 150x160x86mm, Fan: 140mm FAN x1
OUTPUT – VOLCANO 850W
(FULL RANGE + ACTIVE PFC)
VOLTAGE +5V +3.3V +12V1 +12V2 +12V3 +12V4 -12V +5Vsb
MAX LOAD 30.0A 30.0A 18.0A 18.0A 30.0A 30.0A 0.8A 3.0A
MIN LOAD 2.0A 0.5A 1.0A 1.0A 1.0A 1.0A 0.0A 0.0A
PEAK LOAD --- --- --- --- --- --- --- 3.5A
REGULATION +3,-3% +3,-3% +3,-3% +3,-3% +3,-3% +3,-3% +9,-5% +3,-3%
RIPPLE& NOISE
(mV)
50mV 50mV 240mV 240mV 240mV 240mV 120mV 50mV
Continuous total output power is 850 W max.
The combined power of +5V and +3.3V is 180W max.
PSU Cable Set:
1×ATX (20+4), 1×P4 12V, 1×EPS 12V (4+4), 2×PCI-E, 2×PCI-E (6+2) 8×SATA, 10×HDD, 2×FDD
