8
A few things to note for the cooker hood installation using recirculation system:
1. Both carbon filters and filter aluminum should be used.
2. The position of the two filters must be precise.
3. The holes where the air comes out located on the front of the cooker hood cabinet should not be closed.
Note:
Carbon filters are installed at the rear of the grill and must be replaced after three months.
Warning: Carbon filters cannot be washed or recycled. The maximum use of carbon filters is for 120-hour use and must
be replaced afterwards. Carbon filters should not be exposed to the heat
Connect the plug to the power outlet.
Turning on or turning off the cooker hood and cooker hood lights can be done by sliding or pressing a motor speed
regulator button and the lighting button as shown below.
Note: The setting of the cooker hood motor speed is adjusted to the thickness of the smoke / steam that arises when
cooking.
PUSH type button
0 On/ Off Buttons
The Buttons which are for turning off or turning on the cooker hood
Motor speed button – LOW
Suitable for air circulation used in the kitchen or cooking conditions that does not cause a lot of smoke or
steam.
Motor speed button - MEDIUM
Air circulation speed that is suitable for a cooking process that raises a medium volume of smoke or fumes.
Motor speed button - HIGH
When the level of smoke or steam produced is high enough, then use a high-speed level for effective
air circulation.
Buttons to turn on/ off lights
Note: If the low/ medium/ high speed button pressed simultaneously, then the unit will turn on the high speed only.
